Using Your RGBHV to Component Transcoder
3
Table 1: Front Panel FC-14 RGBHV to Component Transcoder
# Feature Function
1 POWER Switch Illuminated switch supplying power to the unit
2 RGBHV Button Selects RGBHV as the input format
3 RGBS Button
Selects RGBS as the input format
4 RGsB Button Selects RGsB as the input format
5 RsGsBs Button Selects RsGsBs as the input format
Table 2: Rear Panel FC-14 RGBHV to Component Transcoder
# Feature Function
1 R IN BNC Connector
2 G IN BNC Connector
3 B IN BNC Connector
Connects to the component video source when selecting
RGB/S or YUV as the input. Automatically detects
whether RGBS or RGsB is input when in the RGB mode
4 H/S IN BNC Connector Connects to the horizontal sync input
5 12V DC Power Connector VDC, 80mA
6 V IN BNC Connector Connects to the vertical sync input
7 R-Y OUT BNC Connector
8 B-Y OUT BNC Connector
9 Y OUT BNC Connector
Connects to the component video acceptor
10 RGBHV IN DB15F Connector Connects to the component video source
5 Using Your RGBHV to Component Transcoder
You can use your FC-14 RGBHV to Component Transcoder to convert the
following source signals to component video signals:
An RGB source (see section 5.1)
An RGBS source (see section 5.2)
An RGBHV source (see section 5.3)
A VGA source (see section 5.4)
