Technical Specifications
9
9
6
Technical Specifications
includes the technical specifications:
Table 3: Technical specifications
INPUT:
of the 7508 CV/YC to SDI Converter
1 composite video, 1Vpp/75Ω on a BNC connector;
1 s-Video, 1Vpp, 0.3Vpp/75Ω on a 4-pin connector
OUTPUT:
2 SDI SMPTE-259M, ITU-R BT.601 on BNC connectors
DIGITAL RESOLUTION:
10 bits
BANDWIDTH:
5MHz (-0.2dB)
S/N RATIO:
57dB
K-FACTOR:
<0.2%
DIFFERENTIAL PHASE:
1Deg
DIFFERENTIAL GAIN:
1%
LUMA NON-LINEARITY:
1%
CHROMA/LUMA DELAY:
<15ns
CONTROL:
Brightness, contrast, hue, saturation, sharpness via RS-232
POWER SOURCE:
12V DC, 210mA
DIMENSIONS:
12cm x 7.5cm x 2.5cm (4.7" x 2.95" x 0.98") W, D, H
WEIGHT:
0.3kg (0.66lbs) approx.
ACCESSORIES:
Power supply, mounting bracket
OPTIONS:
RK-3T 19" rack adapter
1 Specifications are subject to change without notice
