KRAMER: SIMPLE CREATIVE TECHNOLOGY

Technical Specifications

6 Technical Specifications

Table 7 and Table 8 include the technical specifications for the

6410N Digital

to Analog Audio Converter and the

6420N Analog to Digital Audio

Converter, respectively.

Table 7: 6410N Digital to Analog Audio Converter Technical Specifications

INPUTS:

4 digital audio inputs: AES 75 ; AES/EBU; S/PDIF; TosLink Optical

OUTPUTS:

2 analog outputs: balanced line out on detachable terminal blocks;

3.5mm headphone jack

SAMPLE RATE CONVERSION: 32kHz, 44.1kHz, 48kHz, 96kHz
CONVERSION GAIN:

+12dB, +16dB, +20dB,+24dB

BANDWIDTH (+4dBu/-3dBu):

20Hz to 22kHz

MAX. OUTPUT LEVEL:

11.2Vpp @1kHz

S/N RATIO:

88dB

AUDIO THD + NOISE:

-92dB

AUDIO 2nd HARMONIC:

0.003%

CONTROLS:

Input selector buttons, 8 gain switches, headphones level rotary control

knob, 2 LEDs: ON and LINK

POWER SOURCE:

12V DC/1.25A, 150mA

DIMENSIONS:

12cm x 6.95cm x 2.44cm (4.72" x 2.74" x 0.96", W, D, H)

WEIGHT:

.3kg (0.66lbs.) approx.

ACCESSORIES:

Power supply, mounting bracket

OPTIONS:

19" rack adapters

Table 8: 6420N Analog to Digital Audio Converter Technical Specifications

INPUTS:

1 analog input balanced line in (10k) on detachable terminal blocks

OUTPUTS:

4 digital audio outputs: AES 75 ; AES/EBU; S/PDIF; TosLink Optical

SAMPLE RATE CONVERSION: 32kHz, 44.1kHz, 48kHz, 96kHz
MAX. INPUT LEVEL:

11.2Vpp @1kHz

CONVERSION GAIN:

-12dB, -16dB, -20dB,-24dB

CONTROLS:

4 sample rate selector switches, system bit selector switch, 8 gain switches,

ON LED

COUPLING:
