AT-2500TX | PCI Fast Ethernet Adapter Card
Status Indicators
Activity Indicates that there is read/write
activity on the network
10 Indicates 10Mbps operation
100 Indicates 100Mbps operation
PC Interface
Bus Interface PCI, 2.2 compliant
Bus Width 32 bit
Data Transfer Mode PCI Bus Mastering
Ethernet Interface
10T (10Mbps) 2 pair EIA/TIA Category 3, 4 or 5
100TX (100Mbps) 2 pair EIA/TIA Category 5
Programmable Settings
Hardware Interrupts:
PCI INT#A, supports shared or assigned interrupts
Base I/O Memory Address:
Assigned by BIOS
PCI configuration space supports DWORD, WORD and
BYTE access
Driver Support
NDIS 2.01 Artisoft LANtastic
Banyan Vines
DEC Pathworks
FTP PC/TCP for DOS
IBM OS/2
IBM LAN/WARP Server,
DOS and OS/2
SunSoft PC/NFS
Microsoft Windows for Workgroups 3.1,
3.11
NDIS 3.1 Microsoft Windows NT 3.51
(Mini Port Drivers) Microsoft Windows 95, 98, ME, 2000,
XP, 2003
Macintosh OS 8.51, 8.6, 9.0
ODI Server Novell NetWare v3.x, v4.x server, v5.x
ODI Client Novell NetWare DOS Client, Client 32
UNIX Packet Driver SCO System V, Openserver 5.0
Maximum Cabling Distances
10T 100m
100TX 100m
Reliability
Calculated MTBF > 300,000 hours
Power Characteristics
Supply 5vDC at 5W (typical)
Environmental Specifications
Operating Temp. 0°C to 55°C (32°to 131°F)
Operating Humidity 85% at +55°C
Physical Characteristics
Dimensions 12.7cm x 12.1cm
(5" x 4.75")
Half-size form factor
Weight 181.4g (0.4lbs)
AT-2500TX/LP low profile card:
Dimensions
5.7cm x 12cm
Standards & Compliance
IEEE 802.2, 802.3u, ISO, IEC 8802-3
Electrical/Mechanical Approvals
FCC Class A
CUL
CE
Ordering Information
AT-2500TX
Fast Ethernet adapter for 10T and 100TX
AT-2500TX/LP
Low profile Fast Ethernet adapter for 10T and 100TX
20-packs are available for additional saving
