Technical Specifications
Technical specifications of the SID-H are shown in
Table 2: Technical specifications
1
of the SID-H HDMI Step-In Commander
INPUTS:
Video: HDMI
Audio: 3.5mm mini jack
OUTPUT:
TP on an RJ-45 Ethernet connector
STEP-IN COMMANDER
DISTANCE:
50m (164ft)
POWER CONSUMPTION:
12V DC, 360mA
OPERATING
TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE
TEMPERATURE:
–40° to +70°C (–40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
DIMENSIONS:
12.1cm x 7cm x 2.4cm (4.7
” x 2.76” x 0.94”) W, D, H
WEIGHT:
0.3kg (0.66lbs) approx
ACCESSORIES:
Power supply
1 Product details are subject to change without notice
SID-H
HDMI Step-In Commander
Installation Instructions
