KRAMER: SIMPLE CREATIVE TECHNOLOGY

Connecting the VP-300NK 1:3 High Resolution XGA DA

8

5 Connecting the VP-300NK 1:3 High Resolution XGA DA

To connect your

VP-300NK 1:3 High Resolution XGA DA

1

, as the example in

Figure 11 illustrates, do the following

2

:

1. Connect a computer graphics source to the INPUT HD15F connector.
2. Connect the OUTPUT HD15F connectors to up to three

3

acceptors, as

follows:

Connect the OUTPUT 1 connector to acceptor 1 (for example, a

projector)

Connect the OUTPUT 2 connector to acceptor 2 (for example, an

LCD monitor)

Connect the OUTPUT 3 connector to acceptor 3 (for example, a

display)

3. Connect the 12V DC power adapter (wall transformer) to the 12V DC socket

and connect the transformer to the mains electricity.

4. If required, set the:

Hs and Vs switches

ID Bit switch to ON

1 From this section on, all the information is relevant to the VP-200NK, VP-300NK and VP-400NK, unless noted otherwise
2 Switch OFF the power on each device before connecting it to your VP-300NK. After powering up your VP-300NK, switch
on the power on each device
3 Two for the VP-200NK and four for the VP-400NK
