Your XGA Differential Amplifier / DA
3
Table 1: Features and Functions of the VP-200Dxl XGA Differential Amplifier / DA
# Feature Function
1 12V DC +12V DC connector for powering the unit
2 OUTPUT 1 HD15F Connector Connect to the VGA/XGA acceptor 1
3 OUTPUT 2 HD15F Connector Connect to the VGA/XGA acceptor 2
4 ON LED Illuminates when receiving power
5 INPUT HD15F Connector Connect to the VGA/XGA source
6 ID Bit Button Pushing in selects the ID BIT, releasing deactivates the ID BIT
(when outputting the input signal from a notebook connected to an
external VGA monitor 1 )
7 EQ. Control Knob Adjusts the video EQ. (equalization) compensation potentiometer
8 LEVEL Control Knob Adjusts the video signal level potentiometer
4.1 Connecting the XGA Differential Amplifier / DA
To connect the VP-200Dxl, as the example in Figure 2 illustrates, do the
following:
1. Connect a XGA source (for example, a PC graphics card) to the INPUT
HD15F connector.
2. Release the ID Bit button 2 .
3. Connect the OUTPUT (HD15F connectors) to up to 2 acceptors, as
follows:
Connect the OUTPUT 1 (HD15F connector) to the acceptor 1 (for
example, a PC monitor)
Connect the OUTPUT 2 (HD15F connector) to the acceptor 2 (for
example, a projector)
4. Connect the 12V DC power adapter to the power socket and connect the
adapter to the mains electricity.
5. Adjust the video EQ. (equalization) compensation and/or the video signal
level, if required.
1 Sometimes notebook computers refuse to output a VGA signal to an external VGA monitor if they do not detect the ID Bit
as ON (pin # 4 on the VGA connector). Set the ID Bit to ON using this button so that the notebook will output to an external
VGA monitor
2 However, if the source is a notebook (instead of a PC graphics card), push in the ID Bit button
