Connecting the VM-92 9x 1:2 Video Distributor
10
7 Connecting the VM-92 9x 1:2 Video Distributor
This section describes how to connect the VM-92 as a 9 x 1:2 Composite
Video distributor 1 .
To connect the VM-92, as the example in Figure 9 shows 2 , do the following 3 :
1. Connect CHAN. 1 as follows:
Connect a composite video source (for example, a composite video player
1) to the CHAN. 1 IN BNC connector
Connect the CHAN. 1 OUT BNC connectors
4
OUT 1 to acceptor 1A (for
example, composite video recorder 1A), and the OUT 2 to acceptor 1B (for
example, composite video recorder 1B)
Connect a local display to the CHAN. 1 LOOP BNC connector (if
required)
2. Connect CHAN. 9 as follows:
Connect a composite video source (for example, a composite video player
9) to the CHAN. 9 IN BNC connector
Connect the CHAN. 9 OUT BNC connectors 4 OUT 1 to acceptor 9A (for
example, composite video recorder 9A), and the OUT 2 to acceptor 9B (for
example, composite video recorder 9B)
Connect a local display to the CHAN. 9 LOOP BNC connector (if
required)
3. Connect the power cord to the mains electricity.
1 Also see the configuration illustrated in Figure 3
2 Only channels 1 and 9 are illustrated in Figure 9, but you can connect each channel in a similar way
3 Switch OFF the power on each device before connecting it to your VM-92. After connecting your VM-92, switch on its
power and then switch on the power on each device
4 As required. Not all outputs need to be connected
