Technical Specifications
9
7 Technical Specifications
Table 3 includes the technical specifications.
Table 3: Technical Specifications
1
of the VM-50CA
INPUTS: 1 component video (Y, Pb/Cb, Pr/Cr) 1Vpp/0.7Vpp, 75 on 3 RCA connectors
1 digital audio (S/PDIF) 75 on an RCA connector
1 analog stereo audio 50k , +4dBm on 2 RCA connectors
OUTPUTS: 5 component video (Y, Pb/Cb, Pr/Cr) 1Vpp/0.7Vpp, 75 on 15 RCA connectors
5 digital audio (S/PDIF) on 5 RCA connectors
5 analog stereo audio on 4dBm, 150 10 RCA connectors
MAX. OUTPUT LEVEL: VIDEO: 2.3Vpp AUDIO: 1.8Vpp (S/PDIF); 22dBm (analog)
BANDWIDTH (-3dB): VIDEO: 400MHz, Fully
Loaded
AUDIO: 350MHz (S/PDIF); 40kHz (analog)
DIFF. GAIN: 0.08%
DIFF. PHASE: 0.05 Deg
K-FACTOR: <0.05%
S/N RATIO: VIDEO: 76dB @5MHz AUDIO: 90dB (analog)
CROSSTALK (all hostile): AUDIO: -70dB @15kHz, video into audio
CONTROLS: Y, Pb, Pr level: –1.2dB to +6.6dB; analog audio level: -67dB to +6.3dB;
EQ. @50MHz: 0 to +5.9dB
COUPLING: VIDEO: DC AUDIO: analog: Input: AC; Output: DC; S/PDIF: DC
AUDIO THD + NOISE: 0.015% (analog) @1kHz
AUDIO 2nd HARMONIC: 0.003% (analog) @1kHz
POWER SOURCE:
100-240, 50/60Hz, 7VA
DIMENSIONS: 19-inch (W), 7-inch (D) 1U (H) rack-mountable
WEIGHT: 2.6kg (5.7lbs.) approx.
ACCESSORIES: Power cord
1 Specifications are subject to change without notice
