4 VM-4Hxl - Overview
3 Overview
The Kramer VM-4Hxl is a high-quality 1:4 HDMI distributor that accepts an HDMI
input and distributes the signal to four outputs, allowing one or more of the outputs to
be connected to receiving devices, thus making it a versatile, reliable component in a
video system. The VM-4Hxl distributes signals having resolutions up to UXGA,
including all HDTV formats.
In particular, the VM-4Hxl features:
•
A maximum data rate of 6.75Gbps (2.25Gbps per graphic channel)
Suitable for resolutions up to UXGA at 60Hz, and for all HD resolutions.
•
Data reclocking and equalization
•
A default EDID for fast and efficient connection of the unit
The default EDID feature lets you connect the VM-4Hxl without having to connect a
display to the output
•
I-EDIDPro™ Kramer Intelligent EDID Processing™, an intelligent EDID
handling and processing algorithm that ensures Plug and Play operation for
HDMI systems
•
3D pass-through
•
HDMI support for Deep Color, x.v.Color™, Lip Sync, HDMI Uncompressed
Audio Channels, Dolby TrueHD, DTS-HD and CEC
•
Five HDMI connectors, four output status LEDs and EDID read and select
buttons
The VM-4Hxl is housed in a 19" 1U rack-mountable enclosure, and is fed from a
100-240V AC universal switching power supply.
3.1 Defining the VM-4Hxl 1:4 HDMI Distributor
This section defines the VM-4Hxl.
