6 VM-4HN - Connecting the VM-4HN
4 Connecting the VM-4HN
Always switch off the power to each device before connecting it to your
VM-4HN. After connecting your VM-4HN, connect its power and then
switch on the power to each device.
Connect the VM-4HN as illustrated in the example in Figure 2 :
1. Connect an HDMI input source (for example, a DVD player) to the HDMI IN
connector.
2. Connect the four OUTPUT connectors to up to four HDMI acceptors, as
follows:
Not all outputs need to be connected.
 HDMI OUT 1 connector to HDMI acceptor 1 (for example, an LCD TV)
 HDMI OUT 2 connector to HDMI acceptor 2 (for example, plasma
display 1)
 HDMI OUT 3 connector to HDMI acceptor 3 (for example, plasma
display 2)

HDMI OUT 4 connector to HDMI acceptor 4 (for example, plasma
display 3)
3. Connect the 5V DC power adapter to the power socket unit and then
connect the adapter to the mains electricity (not shown in Figure 2 ).
The ON LED lights.
