4 VM-2HD - Overview
3 Overview
The VM−2HD is a high−performance distribution amplifier for HD−SDI signals. It
takes one input, provides reclocking and equalization and distributes the signal to
two identical outputs.
In particular, the VM-2HD features:

A range of up to 200m

Video bandwidth of 1.485Gbps that enables it to be used for standard definition
and high definition serial digital video signals (SD/HD-SDI)

Passing of digital information (embedded audio, Teletext, time code and so
on) during the vertical interval period

SMPTE 292M, 259M and 344M compliance and support for data rates of
143, 177, 270, 360, 540, 1483.5, 1485Mbps

Automatic, multi-rate, equalization and reclocking for losses typical with long
runs of 75

co-axial cable up to 200m

LEDs indicating the SDI resolution
