8 VM-10xl - Connecting the VM-10xl
5 Connecting the VM-10xl
Always switch off the power to each device before connecting it to your
VM-10xl. After connecting your VM-10xl, connect its power and then
switch on the power to each device.
To connect the VM-10xl as illustrated in the example in Figure 3 :
1. Connect a video audio source (for example, a composite video player) to the
VIDEO IN BNC connector and to the left and right AUDIO IN RCA connectors.
2. Connect the 10 VIDEO OUT BNC connectors and the 10 left and right
AUDIO OUTPUT RCA connectors to the video audio acceptors 1 to 10 (for
example, video recorders).
Not all outputs need to be connected.
3. Connect the power cord to the mains electricity.
4. Push in the Term button to terminate the line to 75

.
5. Release the BAL/ST button to select unbalanced stereo audio operation.
6. If required, adjust the video trimmer controls for output signal level and/or
cable compensation equalization level.
Insert a screwdriver into the hole and carefully rotate it, to trim the level.
The video outputs are arranged in two blocks of 5 outputs (outputs 1 to 5, and outputs 6
to 10). Each block can be separately trimmed for output level and cable equalization
(EQ.) thus achieving different compensations for different cable lengths.
7. If audio control adjustment is required for left and/or right gain, push in
Enable/Disable button, and then adjust the trimmer controls.
i
