6 technical specifications, Technical specifications, Table 2: technical specifications of the pt-102vn – Kramer Electronics PT-102VN User Manual
Page 10: Table 2 i ncludes the technical specifications, Table 2: technical specifications, Of the pt-102vn
KRAMER: SIMPLE CREATIVE TECHNOLOGY
Technical Specifications
8
PT-102VN
105VB
105VB
Figure 4: Increasing the Outputs: Arranging a 1:10 DA
6 Technical Specifications
includes the technical specifications:
Table 2: Technical Specifications
INPUTS:
of the PT-102VN
1 Video, 1Vpp /75
Ω
on a BNC connector
OUTPUTS:
2 Video, 1Vpp /75
Ω
on BNC connectors
MAX. OUTPUT LEVEL: 2 Vpp
BANDWIDTH (-3dB):
430MHz
DIFF. GAIN:
0.05%
DIFF. PHASE:
0.05 Deg.
K-FACTOR:
<0.05%
S/N RATIO:
76.1dB
CONTROLS:
Level: -1.2dB to +6dB, EQ.: 0 to + 7.5dB @50MHz via the trimmers
COUPLING:
AC
POWER SOURCE:
12VDC, 30mA
DIMENSIONS:
6cm x 6.5cm x 2.5cm (2.36" x 2.56" x 1") W, D, H
WEIGHT:
0.14kg (0.31lbs) approx.
ACCESSORIES:
Power supply, mounting bracket
OPTIONS:
RK-4PT 19" rack adapter
1 Specifications are subject to change without notice
