106 - Technical Specifications
7
5
Technical Specifications
INPUT:
1 microphone mono balanced on 3 pin terminal block
connector
OUTPUTS:
2 mono balanced line outputs on 3 pin terminal block
connectors
MAX. OUTPUT LEVEL:
27Vpp (22dBm)
BANDWIDTH:
>40kHz
S/N RATIO:
81dB
CONTROLS:
Mic. Type selector pushbutton, -14dB to +68dB LINE
OUT trimmers (MASTER trimmer at max.), +37dB to
+68dB master (LINE OUT trimmer at max.)
COUPLING:
Input: AC, Output: DC
AUDIO THD +NOISE:
0.18%
AUDIO 2nd HARMONIC:
0.16%
POWER CONSUMPTION:
12V DC, 132mA
OPERATING TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE:
-40° to +70°C (-40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
DIMENSIONS:
12 cm x 7.5 cm x 2.5 cm (4.7" x 2.95" x 0.98", W, D, H)
WEIGHT:
0.3 kg (0.66lbs.) approx.
ACCESSORIES:
Power supply (12V, 500mA), mounting bracket
OPTIONS:
RK-
3T 19” rack adapter
Specifications are subject to change without notice at
