104R - Technical Specifications

Technical Specifications

INPUT:

1 RF,

0.5Vpp/75Ω (max.) on an “F” type connector

OUTPUTS:

4 RF, 0.5Vpp/75Ω (max.) on “F” type connectors

BANDWIDTH:

40MHz to 3000MHz (+/−3dB)

COUPLING:

RF GAIN:

+6dB typical across band

NOISE FIGURE:

3.5dB

POWER CONSUMPTION:

12V DC, 80mA

OPERATING TEMPERATURE:

0° to +40°C (32° to 104°F)

STORAGE TEMPERATURE:

-40° to +70°C (-40° to 158°F)

HUMIDITY:

10% to 90%, RHL non-condensing

DIMENSIONS:

12cm x 7.5cm x 2.5cm (4.7” x 2.95” x 0.98”) W, D, H.

WEIGHT:

0.32kg (0.71lbs) approx.

ACCESSORIES:

Power supply, mounting bracket

OPTIONS:

RK−3T 19" rack adapter

Specifications are subject to change without notice at
