Technical Specifications
6
6 Technical Specifications
Table 2: Technical Specifications
1
of the 104B 1:4 Microphone DA
INPUT: 1 microphone mono balanced on an XLR female connector
OUTPUTS: 4 microphone mono balanced on XLR male connectors
MAX. OUTPUT LEVEL: 5.5Vpp
BANDWIDTH (-3dB): >100kHz
S/N RATIO: 86dB
CONTROLS: –3.2dB to +6.7dB level
COUPLING: DC
AUDIO THD + NOISE: 0.13%
AUDIO 2nd HARMONIC: 0.005%
POWER SOURCE:
12 VDC, 193mA
DIMENSIONS: 16. 2cm x 4.36cm x 10.7cm (6.36" x 1.72" x 4.2") W, D, H
WEIGHT: 0.15kg. (0.55lbs.) approx.
ACCESSORIES: Power supply
1 Specifications are subject to change without notice
