Aqua Bath IS6032TS User Manual
Submittal data, Accessible series, Top view - left hand shown

Accessible Series
Submittal Data
IS6032TS
Top View - Left Hand Shown
For additional information, call the
Aqua Bath Customer Service
Department At 1-800-232-2284
9¾"
16"
31½"
I.D.
Ribbed Bottom For
Slip Resistance
51¼"
60" O.D.
54"
80"
83"
84"
36"
76"
24" Grab Bar
20" x 36" Grab Bar
31½" I.D.
32½" O.D.
15½"
1" Dia. S.S. Curtain Rod
Important Note:
Aqua Bath Recommends The Use Of A
Slide Bar As An Accessory In The Unit Rather
Than The Use Of A Glide Bar / Glide Rail.
18"
9"
42"
Front View and Right Side View
Note: Manufacturing Tolerance Of (±1/4”) Due To The Nature Of The Materials Used
Installation: Detailed installation instructions are contained in this catalog, and provided with each unit shipped.
The field installation instructions must be followed as directed or may void manufacturers warranty.
Reference installation instructions for IS6032TS.
Page IS-18
12/08
AQUA BATH COMPANY INC.921 Cherokee Ave.Nashville, TN 372071-800-232-2284Fax (615) 227-9446
www.aquabath.com
