Aqua Bath IS3634SH - Manual

Accessible Series
Submittal Data
IS3634SH 7 3/4”
Top View - Left Hand Shown
For additional information, call the
Aqua Bath Customer Service
Department At 1-800-232-2284
33½"
I.D.
31½" I.D.
15¾"
18"
Ribbed Bottom For
Slip Resistance
27½"
80"
83"
84"
54"
76"
1" Dia. S.S. Curtain Rod
Important Note:
Aqua Bath Recommends The Use Of A
Slide Bar As An Accessory In The Unit Rather
Than The Use Of A Glide Bar / Glide Rail.
34" O.D.
33½" I.D.
36" O.D.
7¾" Threshold
Front View and Right Side View
Note: Manufacturing Tolerance Of (±1/4”) Due To The Nature Of The Materials Used
Installation: Detailed installation instructions are contained in this catalog, and provided with each unit shipped.
The field installation instructions must be followed as directed or may void manufacturers warranty.
Reference installation instructions for IS3634SH 7 3/4".
Page IS-11
12/08
AQUA BATH COMPANY INC.921 Cherokee Ave.Nashville, TN 372071-800-232-2284Fax (615) 227-9446
