CP6030BF Acrylic Pan - Roll-In Shower Unit - ADA Compliant
05/04
 AQUA BATH COMPANY INC.921 Cherokee Ave.Nashville, TN 372071-800-232-2284Fax (615) 227-9446
 www.aquabath.com 
Acrylic Pan - Roll-In Shower - ADA Compliant
• Model CP6030BF
• Acrylic pans designed for new build and renovations of
existing hospitals, nursing homes, rehabilitation centers,
hotels, motels, dormitories and residential applications.
• Meets ANSI A117.1, ADA Guidelines and other standards
for accessibility
• Acrylic one-piece molded construction simplifies installation
with a lightweight durable base.
• Inside dimensions: 60 3/4" W x 30" D x 4" H.
• 3/4" threshold height for top of slab installation.
• Patented integral molded in "Trench Drain System" to help
channel water from the front of the unit to the center drain location.
ROLL-IN SHOWER PAN
Aqua Bath Roll-In Shower Pan CP6030BF is molded from a single sheet of cast acrylic so as not to have any
joints or seams. Shall meet ANSI Z124.2. Shall meet ADA guidelines and other standards for accessibility.
Unit shall have a backside flame spread of less than 30 (Class B). Shall be designed to be ADA COMPLIANT
and NAHB LISTED. The enclosure shall have inside dimensions of 60¾" W x 30" D x 4" H and outside
dimensions of 63½" W x 31¼" D x 6" H. The unit shall be molded with a patented integral recessed "Trench
Drain System" so as to direct water to the center drain location. The approximate weight of the unit shall be 55lbs.
ADA states that the threshold must be flush with the finished floor.
The roll-in shower pan shall be equipped with the following factory installed accessory: 1) Self-caulking brass drain
with stainless steel strainer (not installed). 2) Ribbed bottom for slip resistance (standard).
AVAILABLE OPTIONS
1) Available in model CP6030TD - This unit is the same as the above stated unit except it will have a center front
trench drain located approximately 4" inside of the front flange.
2) ASTM F462 non-slip bottom (see drawing CP6036BF-VB).
(*) When the ASTM F462 bottom is specified with the center drain location, it will re-configure the trench
drain system. A signed off approval is required for the bottom re-configuration.
Modifications: Received and / or approved by:
Please check with your local city and
state for code compliancy. Aqua Bath's
advertised ADA compliant units are
based on our interpretation of the
Americans with Disabilities Act 1991
Guidelines. Field alterations or improper
installation could take the units out of
compliance. Aqua Bath accepts no
responsibility for final code compliance.
For additional information, call the
Aqua Bath Customer Service
Department At 1-800-232-2284
