Page 17: Heat controller, llc

Air pad or extruded
polystyrene
HWG Series
“A” Coil
Air Temperature
Limit Switch
TXV ‘IN’ toward
Compressor Section
PVC Condensate
with vented trap
Indoor Compressor
Section
Air pad or extruded
polystyrene
PVC Condensate
with vented trap
Insulated
Line Sets
Power Disconnects
Low Voltage
TXV ‘IN’ toward
Compressor Section
Indoor Compressor
Section
WDG
Series
17
Installation, Operation & Maintenance
HTS SERIES SPLIT SYSTEM
Heat Controller, LLC
Refrigeration Installation
Figure 12: Typical Split/Air Handler Installation (Indoor Compressor Section)
Figure 13: Typical Split/Add-on Coil Fossil Fuel Furnace Installation (Indoor Compressor Section)
