Australian Monitor Zone Mix 3 - Manual (Page 23)

INSTALLATION SERIES
Australian Monitor
12. SPECIFICATIONS
-Dimensions:
-Weight:
-Power Input:
-Sensitivity (for 0dB out)
44.0 x 482.0 x 286.5 (HxWxD) mm
Net 2.5kg Shipping 3.0kg
Net 5.5lb Shipping 6.6lb
20VAC
30VA max
:
-Max Level Out:
-Frequency Response:
-THD:
-Noise:
-Crosstalk:
-Phantom Power:
Mic/Line Input (RCA)
86mV (-19dB)
All measurements done with levels set to max
Mic/Line Input (XLR)
1.55mV (-54dB)
Prog Input (RCA)
190mV (-12dB)
10Vrms (+22dB)
20Hz - 20kHz
less than 0.1%
-80dB
Better than 65dB
15VDC
All measurements referenced to 0dBu (0.775mV)
(0dB/-3dB)
23
