Model description EQ302 30 band constant Q dual channel graphic equaliser
Input impedance 10 k Ω balanced
Input headroom 8.5 V / +20 dBu
Frequency response (+/-1 dB) 5 Hz – 45 kHz
Distortion (20 Hz - 20 kHz, 0 dBu) < 0.008% THD
Max Output Level 9.5 V / +21.7 dBu
S/N Ratio > 92 dB
Dynamic range > 110 dB
Cross talk @1 kHz > 85 dB
Frequency bands (Q of 4) +/-15 dB on ISO centre frequencies
HP filter control (OUT) flat to 250 Hz, 12 dB / octave
LF contour @ 50 Hz +/-6 dB / octave
HF contour @ 14 kHz +/-6 dB / octave
Connectors (inputs & outputs) XLR, 6.35 mm TRS, Phoenix 5.08 pitch
AC Power 115 / 230V, 50 / 60 Hz, 30 VA
Dimensions (W x D x H) 483 x 180 x 134 mm
(19” x 7” x 5.25”)
Net Weight 3 kg
(6.6 lbs)
Shipping Dimensions (W x D x H) 515 x 275 x 175 mm
(20.3” x 10.8” x 6.9”)
Shipping Weight 4.5 kg
(9.9 lbs)
ACCESSORIES (SUPPLIED)
Power cable (IEC) 1 Pcs
Manual 1 Pcs
PAGE 10 EQ302 INSTALLATION AND OPERATION MANUAL
SPECIFICATIONS
