8
4. 6.35mm TRS output Jack.
This is the line level output of this channel. The 6.35mm jack should be
wired as point (2).
5. Balanced XLR output.
This is the balanced XLR line level output of this channel. The XLR should be
wired as point (3).
6. Unbalanced RCA Input/Output.
These RCA Input/Outputs provide an unbalanced line level input &
output. The RCA connectors should be wired Tip=Positive Sleeve=Ground.
Note: Only one style of connector should be used at one time
.
7. Ground Lift Switch.
The ground lift switch is used to disconnect the signal earth from the mains
& chassis earth. This is used to help eliminate hum caused by ground
loops.
8. Mains Voltage Selector.
This switches mains voltage from 230VAC to 240VAC. Please ensure that
this switch is set to the correct voltage for your part of the world.
9. Fuse Holder.
Both the AMIS215EQ & AMIS31EQ have a 500mA mains voltage fuse.
Set Up & Operation.
Graphic equalizers are used to modify the frequency contour of a sound
system. The graphic equalizer provides a solution to a number of problems
that can be posed by any acoustically challenging environment. The
AMIS series of graphic equalizers are designed to accept a line level
signal from a mixer, professional processor or insert point of an AMIS series
amplifier. The following is a quick set up guide for the AMIS215EQ &
AMIS31EQ.
1. Set the EQ level controls to the centre detent 0dB position.
2. Select the Bypass switch to the “on” position (red LED illuminated).
