3. Outputs

Type;

Active balanced/unbalanced

Connectors;

3 pin XLR, 6.35mm TRS balanced, RCA unbalanced

Impedance;

<150 Ohms Typical

Max Level;

+22dbm (2k ohms)

+18dBm (600 ohms)

4. Rfi Filters;

Yes

5. Passive Bypass Switches; Yes

6. Overload LED Switches; 5dB below clipping

7. Low Cut Filter;

10-250Hz, 12dB per octave

8. High Cut Filter;

3kHz-40kHz, 12dB per octave

9. Frequency Response;

20Hz-20kHz

10. IM Distortion (SMPTE); 0.005%

11. Signal to Noise Ratio;

-94dB (20kHz noise bandwidth)

12. Channel Separation;

50dB

13. Common Mode Rejection;

50:1

14. Voltage;

190-250VAC, 50Hz

15. Dimensions;

44.5mm (h) x 483mm (w) x 216mm (d)

16. Weight;

2.5kg
