Specifi cation Conditions
Frequency response:
Mic/Line Inputs ----->Line Level Output 20-20 kHz, -3 dB Signal Input -2 dB below clip
Mic/Line Inputs ----->Amp Output 60-20 kHz, -3 dB Signal Input -2 dB below clip
Stereo Inputs ---->Line Level Output 20-20 kHz, -3 dB Signal Input -2 dB below clip
Stereo Inputs ---->Amp Output 60-20 kHz, -3 dB Signal Input -2 dB below clip
Total Harmonic Distortion:
Mic/Line Inputs ----> Line Level Output <0.05 % 0 dB gain, Signal input -2 dB below clip
Mic/Line Inputs ----> Line Level Output <0.1 % 45 dB gain, Signal input -2 dB below clip
Mic/Line Inputs ---> Amp Output <0.5 % Signal input -2 dB below clip
Stereo Inputs ---> Line Level Output <0.05 % Signal input -2 dB below clip
Stereo Inputs ----> Amp Output <0.5 % Signal input -2 dB below clip
Input Impedance:
Mic/Line
Mic: 1.5 k
Line: 1.5 k
Stereo Input 12 k
Max Input
Mic/Line Input 22 dBu Mic/Line pad on
2 dBu Mic/Line pad off
Stereo Input 6 dBu
Mic/Line Pad Switch: 20 dB pad
Maximum Voltage Gain:
Mic/Line Inputs 45 dB With 45 dB gain switch (analog domain)
Phantom Power: +34 VDC Available via individual switch on each mic/line channel
Cross Talk: > 80 dB 1 kHz, input channel at clip, measured on line output of adjacent output
S/N Ratio:
Mic\Line Input > 92 dB A-weighted, to line and amp output, 20 Hz to 20 kHz
Stereo Input > 91 dB A-weighted, to line and amp output, 20 Hz to 20 kHz
Max Output
Line Level Ouptut 10 dBu Balanced (+4 dBu unbalanced on each leg)
PAGE 18 AMD100/200 INSTALLATION AND OPERATION MANUAL
SPECIFICATIONS
