SN0108 / SN0116 User Manual
92
RJ-45 to Serial Adapters
RJ-45 to Serial adapters are not included with the SN0108 / SN0116 package.
To purchase these adapters, contact your dealer. The tables on the following
pages describe the available adapter configurations.
SA0141: RJ45-F to DB9-F (Black Connector)
DTE to DTE
SA0142: RJ45-F to DB9-M (Black Connector)
DTE to DCE
SN0108 / SN0116 (RJ45)
Pins (8)
Computer (DB9)
RTS
1
<————————>
8
DTR
2
<————————>
6+1
TXD
3
<————————>
2
CTS
4
<————————>
7
GND
5
<————————>
5
RXD
6
<————————>
3
DSR
7&8
<————————>
4
9 NC not used
SN0108 / SN0116
(RJ45)
Pins (8)
Modem/Device
(DB9)
RTS
1
<————————>
7
DTR
2
<————————>
4
TXD
3
<————————>
3
CTS
4
<————————>
8
GND
5
<————————>
5
RXD
6
<————————>
2
DCD
7
<————————>
1
DSR
8
<————————>
6
9 NC not used
