EURO • Printed in England • GB • F016 L69 838 • CLUB/ROYALE • OSW 08/01
English - 2
Cylinder Mower Club 20 I/C Royale 20E I/C Royale 24E I/C Royale 30E I/C
Professional
Part number F016 312 142 F016 310 442 F016 310 542 F016 310 642
Engine type B&S Intek Pro B&S Intek Pro B&S Intek Pro B&S Intek Pro
Engine speed (rpm) 2 800 2 800 2 800 2 800
Engine size (cm
3
) 206 206 206 206
Fuel Tank capacity (l) 4.1 4.1 4.1 4.1
Electric start no yes yes yes
Rated power (kW) 6.5 6.5 6.5 6.5
Blade width (cm) 51 51 61 76
Height of cut (mm) 2.8 – 18 5 – 35 5 – 35 5 – 35
Cuts per metre 146 73 73 73
Grassbox capacity (l) 60 76 99 126
Weight (kg) 92 103 111 135
Max overall width (cms) 77 70 79 94
Serial Number See rating details on machine
This product is intended for domestic and commer-
cial lawn mowing.
Note: commercial use does not include rental/hire
use.
This manual gives instructions on the correct assem-
bly and safe use of your machine. It is important that
you read these instructions carefully.
When fully assembled the machine weighs approxi-
mately 92 – 135 kg. If necessary, obtain assistance to
remove from packaging.
Take care when transporting the mower to the lawn,
as the blades are sharp.
Carefully remove the machine from its packaging and
check that you have all the following items:
– Lawnmower with handle assembly
– Operating instructions
– Spare parts list
– Tool kit
When parts are missing or damaged, please contact
your dealer.
1 Handle
2 Drive lever
3 Ignition key (electric start models only)
4 Engine
5 Petrol filler cap
6 Oil filler cap
7 Grassbox
8 Height of cut knob
Not all of the accessories illustrated or described are
included as standard delivery.
Handles
Assemble the handles as shown and fit the throttel le-
ver.
Engine Oil
The mower is not supplied with oil in the en-
gine, however it is possible that there is a small
quantity in the engine. It is essential to fill with
oil before starting the engine it avoid damage to
your engine. It is important to use the recom-
mended oil to avoid damage to your engine.
The engine is fitted with a switch that will prevent the
engine from starting without suffcient oil.
1. With the mower standing on level ground, un-
screw and remove the oil filler dip stick 9 .
2. Wipe the oil filler dip stick 9 clean; refit and
tighten the oil filler dip stick 9 , then remove it
again. Check the oil level.
Product Specification
Intended Use
Introduction
Delivered Items
Operating Controls
Assembly
A
B
