34
Effective 09/01/2003
To order replacement parts, contact AquaCal Customer Support: (800) 786-7751
REPLACEMENT PARTS
VOLTAGE : 1/60/208-230 VOLTAGE : 3/60/208-230
CONTROL BOX COMPONENTS T65”X”-A T115”X”-A T135”X”-A T65”X”-B 115”X”-B 135”X”-B
PART DESCRIPTION PART NUMBER PART NUMBER
THERMOSTAT,HONEYWELL POTTED 6270 6270 6270 6270 6270 6270
THERMOSTAT, AMBIENT AIR (RANCO) 7048 7048 7048 7048 7048 7048
TIME DELAY, 5 MINUTE ON BREAK 6102A 6102A 6102A 6102A 6102A 6102A
TERMINAL BLOCK, 10 LUG WECO 6318 6318 6318 6318 6318 6318
TRANSFORMER, 208/240 - 24 50 VA. 6209 6209 6209 6209 6209 6209
CONTACTOR 6061 6061 61001 6147 6147 6147
CAPACITOR FAN 6051 6051 6051 6051 6051 6051
SWITCH, WATER PRESSURE SPDT 6248 6248 6248 6248 6248 6248
GROMMET, 7/8" BLACK PLASTIC 6022 6022 6022 6022 6022 6022
GROUND LUG, ADR-2 6020 6020 6020 6020 6020 6020
CONNECTOR,SOCK. HOUSING 20 PIN 6276 6276 6276 6276 6276 6276
CAPACITOR, RUN 6056 6057 60500 N/A N/A N/A
CONN. 1/2 ST. THRU LIQ. TIGH. HEYCO#3200 6701 6701 6701 6701 6701 6701
LOCKNUT, 1/2 BLK NYLON #NLN12B 9164 9164 9164 9164 9164 9164
TERMINAL BLOCK, 9 POLE WECO 6316 6316 6316 6316 6316 6316
PHASE ROTATION MONITOR N/A N/A N/A 6035 6035 6035
MAJOR COMPONETS VOLTAGE : 1/60/208-230 VOLTAGE : 3/60/208-230
T65”X”-A T115”X”-A T135”X”-A T65”X”-B 115”X”-B 135”X”-B
PART NUMBER PART NUMBER
FAN GRILLE 7109 7109 7109 7109 7109 7109
FAN MOTOR 3114 3114 3114 3114 3114 3114
FAN BLADE 3104 3104 3104 3104 3104 3104
EVAPORATOR COIL ACP0001 ACP0001 ACP0006 ACP0001 ACP0001 ACP0006
CONTOL BOX PANEL ASSEMBLY HPA0015 HPA0015 HPA0015 HPA0015 HPA0015 HPA0015
TITANIUM COIL / HEADER FIELD KIT CDK0008 CDK0009 CDK0010 CDK0008 CDK0009 CDK0010
COMPRESSOR 4323 4623 4729 CR33KQ-
TF5-240 4623-TF5
ZR81KC-
TF5-235
TSTAT SENSOR / WELL 6105D 6105D 6105D 6105D 6105D 6105D
TXV REP0007 REP0004 REP0005 REP0007 REP0004 REP0005
BASE-PLASTIC PCP0018 PCP0018 PCP0019 PCP0018 PCP0018 PCP0019
CONTROL PANEL HPA0007 HPA0007 HPA0007 HPA0007 HPA0007 HPA0007
FILTER DRIER 2036 2036 2036 2036 2036 2036
PLASTIC, 120 DEGREE COVER, BLACK PCP0005 PCP0005 N/A PCP0005 PCP0005 N/A
PLASTIC, 150 DEGREE COVER, BLACK PCP0004 PCP0004 N/A PCP0004 PCP0004 N/A
PLASTIC, 90 DEGREE COVER, BLACK 70100 70100 70100 70100 70100 70100
