Installation
Replacement Timer
Remove old timer by disconnecting the motor lead wires
from the motor terminals and the power supply wires
(typically red and black in color) from the battery terminals.
Now proceed to “New” timer installation instructions.
New Timer
Connect Motor Wires
Identify the blue and white wires extending from the right
hand side of the timer unit. Once located, install the blue
wire to the red wire from the motor. Install the white wire to
the black wire from the motor. If wires are reversed, it only
changes direction of spinner plate and does not damage
the unit.
Install Battery
The Model# VTX-D is designed for 6-Volt battery operation
(For peak performance, we recommend that you use the
Model# VTX-D digital timer with a rechargable battery).
Identify the two (2) power supply wires extending from the
