Bluetooth EZ-Extender Manual
2-3
Bluetooth EZ-Extender Hardware Reference
The board contains a Bluegiga WT12 class 2, a Bluetooth 2.0, and EDR
module, described in
“Bluetooth Module” on page 1-5
is equipped with an I
2
C serial flash memory chip for data storage and
configuration.
Configuration Switch
This section describes the board’s configuration switch (
SW1
). The switch
location is shown in
Figure 2-2. Configuration Switch Location
