6
Glastender, Inc. • 5400 North Michigan Road • Saginaw, MI • 48604-9780
800.748.0423 • 989.752.4275 • Fax 989.752.4444 • www.glastender.com
e
leCtriCal
aNd
r
efrigeratioN
S
PeCifiCatioNS
lP60, lP84, lP108 m
odelS
e
leCtriCal
r
efrigeraNt
P
reSSure
P.S.i.g
120V, 1 phase, 60 Hz, 6.5 full load amps, 1/4 HP
t
yPe
R134a, C
harge
16.0 oz.
h
igh
350, l
ow
88
w
iriNg
d
iagram
Gree
n
C
Overload
Blue
1 2 3 4
6 78 9
Orang
e
Orang
e
Blue
Mate
N' Lock
Transformer
Compressor
Black
Gree
n
Whit
e
Blue
White
Blue
Whit
e
White
Fans Per
Unit Varies
Lights Per
Unit Varies
12
VDC
120/240
VA
C 50/60HZ
Digital Controller
Self Contained
Units Only
Orang
e
Blue
Orange
Self-
Contained
Unit
Evaporator
Cond Fan
White
Start Capacitor
Star
t Rela
y
Optional
230VAC 50/60HZ 1 PH
Blue
Whit
e
Evap Fan
Evap Fan
Switch
Lights
Te
mp
Pr
ob
e
Whit
e
R
S
Supply
Power Supply
120VAC 60HZ 1PH
1 2 3 4
6 78 9
Re
d
Te
mp
Pr
ob
e
Supply
White
Blue
Controller supply wires
will be jumpered to the
main controller by
matching numbers
Mate
N' Lock
Blue
White
+
-
Blower Motors
Wine Chiller
Controller
Blowers per
unit varies
Optional Beer Tower
Blower Package
Optional Wine
Chiller Package
Wiring For
Optional Packages
Re
d
