Installation and Operating Instructions
Model ICM/ICMP, for life grease lubrication
9330-050-en Revision 05
TM 5409 MPE/Re/Wm Page 5 Date 03/2003
1.2 Tightening torques
Screws greased, tighten in diametrically opposite se-
quence
Housing screws 901/3
Pump size No. x size Nm
Group 1
40-25-160 8 x M12 40
50-32-160 8 x M12 40
65-40-160 8 x M12 40
80-50-160 8 x M12 40
40-25-200 12 x M12 40
50-32-200 12 x M12 40
65-40-200 12 x M12 40
80-50-200 12 x M12 40
Group 2.1
100-65-160 12 x M12 40
125-80-160 12 x M12 40
100-65-200 12 x M12 40
125-80-200 12 x M12 40
125-100-200 12 x M12 40
Group 2.2
40-25-250 8 x M16 50
50-32-250 8 x M16 50
65-40-250 8 x M16 50
80-50-250 8 x M16 50
100-65-250 8 x M16 50
125-80-250 8 x M16 50
50-32-315 16 x M16 50
65-40-315 16 x M16 50
80-50-315 16 x M16 50
Pipe screws, flanges to DIN/ISO
DN No. x size Nm
25 4 x M12 12
32 4 x M16 18
40 4 x M16 22
50 4 x M16 30
65 4 x M16 40
80 8 x M16 25
100 8 x M16 40
125 8 x M16 55
Impeller nut 231
No. x size Nm
Group 1 1 x M12x1,5 35
Group 2 1 x M16x1,5 70
Plain bearing cartridge screws 901/1
3 x M8 12 Nm
1.3 Type plate, dry-running, CE
and housing markings
The stainless steel type plate is firmly riveted to the
bearing pedestal :
If the operator attaches his identification, it must be
ensured that the pump matches the application in
question.
Example of type plate:
Dry-running :
CE-marking :
Housing identification:
The following are visible on the housing according to
DIN EN 19:
♦ Nominal size
♦ Rated pressure
♦ Housing material
♦ Manufacturer's identification
♦ Melt number/Foundry identification
♦ Foundry
date
