Installation and Operating Instructions
Model ICM/ICMP, for life grease lubrication
9330-050-en Revision 05
TM 5409 MPE/Re/Wm Page 3 Date 03/2003
Relevant documents
♦ Data sheet
♦ Sectional drawing pumps
♦ GA drawing
♦ Performance curves
♦ Spare parts list
♦ Operating manual motor *
♦ Operating manual coupling *
♦ Declaration of conformity for the entire unit to Ma-
chine Directive 98/37/EC
♦ Pump to ATEX :
Declaration of conformity for the pump to Directive
94/9/EC *
* if contained in the scope of delivery
1 Technical Data
Manufacturer :
ITT Goulds Pumps
Millwey Rise Industrial Estate
Axminster, Devon,
EX13 5HU
UK
Tel : +44 (0)1297-630250
Fax : +44 (0)1297-630256
Designation :
Model ICM Magnetic Chemical Process Pump,
bearing lubrication: grease.
Model ICMP Magnetic Chemical Process Pump for
high pressure / high temperature appli-
cations, with center-line mounted cas-
ing, bearing lubrication: grease.
Technical specifications to ISO 15783 and
DIN ISO 5199
Connecting dimensions to ISO 2858 / DIN EN 22858
Flange connecting dimensions :
DIN EN 1092-2, type B
(ISO 7005-2, type B) PN 16
ATEX 100a Directive 94/9/EC
Machine Directive 98/37/EC
Materials :
Standard ICM/ICMP: Stainless steel (1.4408),
Optional ICM:
Ductile cast iron/ cast iron, Du-
plex, Hastelloy C, titanium
Optional ICMP: Steel/cast iron, Duplex, Hastel-
loy C, titanium
Flow rates : up to 340 m 3 /h (at 2900 rpm)
Delivery heads : up to 150 mLC (at 2900 rpm)
Housing discharge pressure :
ICM 16 bar
(max. 25 bar with 65-40-315, 50-32-315 and 80-50-315)
ICMP
25 bar
Temperature range : -40° C to +180° C
With temperatures up to 280° C oil bath lubrication
has to be used
Note: Consult the manufacturer for higher pressures
and lower or higher temperatures.
Temperature classes : see Section 2.5.6
Sizes:
Group 1 Group 2.1 Group 2.2
40-25-160 * 100-65-160 40-25-250 *
50-32-160 125-80-160 50-32-250
65-40-160 100-65-200 65-40-250
80-50-160 125-80-200 80-50-250
40-25-200 * 125-100-200 100-65-250
50-32-200 125-80-250
65-40-200 50-32-315 *
80-50-200 65-40-315
80-50-315
* Low-Flow sizes :
not included in ISO 2858 / DIN EN 22858
not as model ICMP
Weight :
See installation drawing
Dimensions :
See installation drawing
