CS1642 / CS1644 User Manual
20
Keyboard Operating Platform
The CS1642 / CS1644’s default port configuration is for a PC compatible
keyboard operating platform. If your console uses a PC compatible keyboard
and you have a Mac or Sun attached to a port, for example, you can change the
port’s keyboard operating platform configuration so that the PC compatible
keyboard emulates the Mac or Sun keyboard. The procedure is as follows:
1. Bring the KVM focus to the port you want to set.
2. Invoke HSM (see page 18).
3. Press and release the appropriate Function key (see table below). After
completing this procedure, you automatically exit HSM.
List Switch Settings
To see a listing of the current switch settings, do the following:
1. Open a text editor or word processor and place the cursor in the page
window.
2. Invoke HSM (see page 18).
3. Press and release [F4] to display the settings.
Function Key Operation
[F2] Enables Mac keyboard emulation, see page 25, for
details.
[F3] Enables Sun keyboard emulation, see page 26, details.
[F10] Auto detects the keyboard operating platform (for PC
compatible systems). Activates Pass Through keyboard
mode (keystrokes are sent directly to the computer
instead of through the Mac or Sun emulator).
