INSTALLATION INSTRUCTIONS
OVERVIEW
STEP ONE: INVENTORY
STEP TWO: SUSPENSION HARDWARE
A) SINGLE CABLE SUSPENSION
B) DOUBLE CABLE SUSPENSION
STEP THREE: INSTALLATION OF FABRIC DIFFUSER
STEP FOUR: START UP
WARRANTY
CLEANING AND REPAIR
STEP ONE:
INVENTORY
Before installing fabric diffuser system read all general information in the following sections. For best
results use this manual in conjunction with the mechanical blue print or diffuser layout if supplied.
Check the shipment carefully. Diffuser systems are shipped in polyethylene bags or boxes. Larger or-
ders will be shipped in large skidded containers with individual contents in polyethylene bags or folded.
All packages will be labeled with diffuser diameter and length.
Make sure contents match the packing list. Note any missing or damaged pieces and notify your sup-
plier before starting installation. Check length & diameters before installing & contact supplier before
installation. (Not responsible for labor costs accrued from installing incorrect lengths or layouts.)
204 Hallberg St.
PO BOX 507
Delavan, WI.
53115
FlowCon
Fabric Air Diffusers
Cable Installation Guide
