INSTALLATION INSTRUCTIONS OVERVIEW
STEP ONE: INVENTORY
STEP TWO: SUSPENSION HARDWARE
STEP THREE: INSTALLATION OF FABRIC DIFFUSER
STEP FOUR: START UP
WARRANTY
CLEANING AND REPAIR
STEP ONE:
INVENTORY
Before installing fabric diffuser system read all general information in the following
sections. For best results use this manual in conjunction with the mechanical blue
print or diffuser layout if supplied.
Check the shipment carefully. Diffuser systems are shipped in polyethylene bags or
boxes. Larger orders will be shipped in large skidded containers with individual con-
tents in polyethylene bags or folded. All packages will be labeled with diffuser diame-
ter and length.
Make sure contents match the packing list. Note any missing or damaged pieces and
notify your supplier before starting installation. Check length & diameters before in-
stalling & contact supplier before installation. (Not responsible for labor costs accrued
from installing incorrect lengths or layouts.)
204 Hallberg St.
PO BOX 507
Delavan, WI.
53115
FlowCon
Fabric Air Diffusers
Flush Rail Installation Guide
