4 3
Display Error Cause
max Positive excess of the measuring range The measured value exceeds the max. of the range
min Negative excess of the measuring range The measured value is lower than the min. of the range
anao Failure of the analog output Output loop is not closed or short circuited
sens Sensor failure (internal) Sensor bridge not in balance, might be been overloade
data Stored data failure (EEProm) (internal) Memory failure
prog Processor failure (internal) Microcontroller failure
cal Calibration failure (internal) Calibration values are wrong
4. Operation
After the unit is switched on, the unit starts an automatic self-test.
The device is menu operated and configured by the three keys on the front.
With the „M“ key (= mode) you change between the operation / indicating level to the dialog values and the
adjusted / actual values. With the keys („
⇑“ = up) and („⇓“= down) you change between the dialog values
in the menu or change the values / functions in the menus.
A change of any configuration starts always with the M-Mode and indicated by the flashing cursor. After a
change has been made the M-mode key must be pressed to confirm each configuration; to set numbers,
each digit has to be confirmed with the M-Mode before adjusting the next one. By confirming the last digit
the new configuration will be stored in the memory.
Pushing the down key at the end of the sub-menu the software will switch automatically to the main-menu.
For a quick termination of programming you can change into the measuring mode from any level in the
menu by pressing the M-key for 5 seconds.
If the dialog is not continued within two minutes the device automatically returns to the measuring mode
without accepting the new values (see also: „List of functions“).
5. Key lock
Activating the („ ⇑“ = up) and („⇓“ = down) keys together for more than 5 seconds will block any changings
in all menues; shown by „LOCK“ in the display.
In this mode, all configuration values can be checked only, but not changed.
Repeating this action will unlock the configuration menu and shown by „UNLK“ in the display.
6. Error handling
The internal self-check software will monitor the proper functioning of the unit. When any of the following
failures will occur, the flashing display will indicate the following text:
List of functions
Main Menu Sub Menu Value Description
Measuring .... Display of the actually measured value
mode and the measuring unit
MENU Display keylock
UNLK No keylock, all parameters can be adjusted
LOCK Keylock active, all parameters visibal but can not be changed
SP.1 ... SP.4 Switchpoint menu SP1..SP4
MODE STND Standard evaluation (rising/falling)
WIND Window technology
ERRO Error output
ON .... Switch-on value for SP1..SP4; if the ON-value is smaller
than the OFF-value, the switch evaluatiuon is falling
OFF .... Switch-off value SP1..SP4
LEV Inversion of the switching output SP1...SP4
HLFS High-level-fail-safe (Normally Open function)
LLFS Low-level-fail-save (Normally Closed function)
DEL 0,0s..9,9 s Switch-on / switch-off delay for SP1...SP2 in seconds
ANOP Analog output menu
ANOP ON Analog output in operation
OFF Analog output switched off
AOZS .... Scale the analog output - start value (e.g. 0 bar=4mA)
AOFS Scale the analog output - end value (e.g. 400bar=20mA)
DISP Display menu
UNIT bar Adjustment of the measuring unit, the recalculation to the new
(only PSI unit value is done automatically
UDS3) MPa
:
DAMP 0,0s..9,9 s Damping of the displayed measuring value in seconds
OFFS .... Measuring value -Offset, means shifting the display range
CUT .... Cut-Off, means signal-surpression within the cut-off range
BGZS .... Scale the bargraph - start value
BGFS .... Scale the bargraph - end value
PEAK Peakholding menu
MIN .... Display the peak value „Min“
CLRM NO no deletion
YES delete „Min“-value
MAX .... Display the peak value „Max“
CLRX NO no deletion
YES delete „Max“-value
CAL Calibration menu
(only UAS3) DECP 0000..0,000 Declaration of the decimal-point for the measuring value
ZSCL .... Scale the measuring-value indication - start value
FSCL .... Scale the measuring-value indication - end value
UNIT bar Declaration of the measuring unit
PSI
:
TEXT
Enables the indication of the measuring-unit whitch is defined
in the UTXT menu
UTXT ABCD Programm a free configurable text for the measuring unit
CODE Calibration menu for the manufacturer
