11
Fig. 21 Fig. 20
1. Disassemble the switch housing from the light
kit, you can keep the light kit for future use.
(Fig. 20)
2. Attach the plug to the switch housing. (Fig. 21)
3. Holding the switch housing under your fan,
snap together the wire connection plugs .
4. Install the switch housing to the mounting
plate with screws provided. (Fig. 21)
FAN WITHOUT LIGHT KIT
SCREWS
SWITCH
HOUSING
MOUNTING PLATE
PLUG
MOLEX
NUT
LOCK WASHER
SWITCH CUP
LIGHT KIT
