Attaching the switch cup – Minka Group F539-BN User Manual
Page 17
Step 1. Remove the screws from the switch cup plate. Connect the switch cup and fan
wire molex connectors, Place the switch cup over the switch cup plate and secure
with screws previously removed. (Fig.20).
NOTE: DO NOT PINCH WIRES BETWEEN THE SWITCH CUP AND THE SWITCH CUP
PLATE.
ATTACHING THE SWITCH CUP
9
Fig.20
CAP
SCREW
LIGHT KIT
MOLEX
