After all splices are made, check to make
sure there are no loose strands. As an
additional precaution we suggest to secure
the plastic wire connectors to the wires
with electrical tape.
Note: Fan must be installed from a maximum
distance of 40 feet from the transmitting
unit for proper signal transmission between
the transmitting unit and the fan's receiving
unit.
Fig.13
Fig.12
Fig.14 Fig.15
RECEIVER
OUT LET
BOX
RECEIVER
FAN
DOWNROD
HANGER
BRACKET
RECEIVER
WALL
CONTROL
GROUND
GREEN
GREEN
BLACK
BLACK BLACK
BLACK
Step 4. If your outlet box has a GROUND
wire (Green or Bare Copper) connect this
wire to the Hanger Ball and Hanger Bracket
Ground wires. If your outlet box does not
have a Ground Wire, then connect the
Hanger Ball and Hanger Bracket Ground
Wires together. Secure wire connection
with the plastic wire nut provided. (Fig. 14
& 15)
