Meteor Spinner D3 User Manual
Page 2

2
INSTALLING GLASS GOBOS:
1
Remove large (thicker) retaining wire clip.
2
Remove the retaining washer
3
Place Glass Gobo in Gobo housing.
4
Locate “thin” retaining wire Clip
5
Squeeze together and insert into groove on wheel]
INSTALLING METAL GOBOS:
1
Remove large (thicker) retaining wire clip
2
Place the “Retaining Washer” on wheel
3
Place the METAL GOBO on Retaining Washer
4
Using the “thicker” retaining wire clip.
5
Squeeze together and insert into wheel groove.
Note:
Regardless of which types of gobo you are using – you will not be using two (2) of the 4 “wire clips. Put them in a
place that you will remember where they are – in case you need to change out from one style to another. If you are using
glass – you will not need the retaining washer either. Put that in the same safe place.
SETTING THE BASE ADDRESS / DIP SWITCHES. *
(SET SWITCHES FROM LEFT TO RIGHT 1-10)
1
Based on Basic Binary Configuration (with Base Address 1 as a value of 1)
2
To Start - All Dip switches in OFF position.
3
Unit 1 – Base Address 1 – First switch ON
4
Address 2 will be switch 2 ON
5
Address 3 will be switches 1 and 2 ON and so forth.
INSERTING SPINNER D3 INTO ELIPSOIDAL:
1
Locate accessory slot on top of Elipsoidal.
2
Loosen two top screws (usually Phillips) and slide panel back.
3
Insert SPINNER 3D.
4
Close accessory cover so that it is up against rotator.
5
Tighten screws back down
.
USING SPINNER D3 WITHOUT DMX – DIP SWITCH 10 ON:
The tenth switch (#10) is not used for the DMX address, so we gave it a TEST Function / RUN .When this is
operated, the DMX receiver is switched OFF, and you can use 8 of the DIP-switches to set the desired motor
speeds, forward or reverse, 7 speeds and stop.
It means that you can get the motors Rotating in the absence of a DMX desk (manual mode) – more then likely
– to be used for RENTAL APPLICATIONS:
1- Put switch 10 on.
2- Set any of the first switches on / off to a setting of your liking for either Speed or Direction
3-
Both motors will /can operate at same speeds, but opposite directions at the same time.
In MANUAL / TEST MODE (switch 10 on), switches 1,2,3,4 control the speed of the first motor.
So start from Switch 10 ON, rest off.
MOTOR 1
As you change the codes, you should see the following behavior on one motor, while the other is stationary.
0 = off, 1 = on:
1 2 3 4 - SWITCHES
1 0 0 0 slow forward
0 1 0 0 faster
1 1 0 0 faster
0 0 1 0 faster
1 0 1 0 faster
1 1 1 0 fastest forward
