DMX SPINNER D3
USER MANUAL / OPERATION INSTRUCTION
SPINNER D3
SPINNER D3
SPINNER D3
SPINNER D3
Thank you for purchasing our new, truly one of a kind, DUAL MOTOR – DUAL GOBO –
2 CHANNEL DMX
GOBO ROTATOR.
Following the tremendous success that METEOR has had with the SPINNER 2 GOBO
ROTATOR. The only natural evolution process, in keeping up with today’s technology and ever-changing
needs in the THEATRICAL INDUSTRY, was to take the SPINNER 2 to the next level by making the speed and
direction of BOTH motors operational via DMX from your controller.
By being completely assembled / manufactured at our facility here in Madison Alabama, allows use to pay
specific attention to detail and quality assurance and quality of the product.
We have designed the SPINNER D3
D3
D3
D3
to accommodate either Glass or Metal Gobos. The unit comes complete,
without having to purchase “adapter kits” or “power distribution” packs or ANY additional equipment to operate
at its fullest capacity.
We have also taken the time to make the SPINNER D3 user friendly. Meaning that according to our design,
these units will fit in the majority of the common elipsoidals used in today’s industry. Simply put, they will work
in a ETC SOURCE 4™, ALTMAN SHAKESPEARE™, SELECON PACIFIC™, SELECON ACCLAIM™ and
now also available for the LEVITON LEO™ and various other brands.
TECHNICAL SPECIFICATIONS:
POWER:
120VAC/ (240VAC OPTIONAL)
DMX CONNECTOR:
5 PIN XLR
MOTORS:
2 – 24VDC
SPEEDS:
VARIABLE via DMX CONTROL
DIRECTIONS:
INDEPENDENT CLOCKWISE / COUNTERCLOCKWISE MOVEMENT
GOBO HOLDER:
2 - GLASS or METAL GOBOS
GOBO SIZE:
“B” SIZE GOBOS
SIZE:
11.50”H X 4.70”W
WEIGHT:
2.5 LBS.
POWER SUPPLY:
1 - U.L –24VDC REGULATED POWER (included)
DMX PROFILE:
2 CHANNEL DMX – 5 PIN XLR (Profile)
Channel 1:
0
Off
1-119
increasing speed rotation clockwise
120-127
Off
128-247
increasing speed rotation – counterclockwise
248-255
Off
Channel 2:
0
Off
1-119
increasing speed rotation clockwise
120-127
Off
128-247
increasing speed rotation – counterclockwise
248-255
Off
