DMX- Protocol:
CONTROL CHANNEL - 11
DMX Value FEATURES/ ATTRIBUTES
CH. 1 COLOR 0 - 7 WHITE
8 - 15 PINK
16 - 23 YELLOW
24 - 31 BLUE
32 - 39 ORANGE
40 - 47 GREEN
48 - 55 LIGHT PINK
56 - 63 LIGHT PURPLE
64 - 127 GRADUAL COLOR CHANGE
128 - 191 POSITIVE RAINBOW EFFECT w / increasing speed
192 - 255 REGRESSIVE RAINBOW w / decreasing speed
CH. 2 GOBO 1 - 15 CIRCLE
16 - 31 SPIRAL
32 - 47 BREAKOUT
48 - 63 HAZARD
64 - 79 DESIGN
80 - 95 TRIANGLE
96 - 111 FIRE
112 - 127 SUN
128 - 191 POSITIVE RAINBOW EFFECT w increasing speed
192 - 255 REGRESSIVE RAINBOW w / decreasing speed
CH. 3 GOBO 1 - 15 STATIC
ROTATE 16 - 135 SPEED GOBO - CLOCKWISE (right to left)
136 - 255 SPEED GOBO - counter - CLOCKWISE (left to right)
CH. 4 SHUTTER 0 - 15 SHUTTER CLOSED
16 - 128 DIMMER CONTROL
129 - 133 WHITE
134 - 243 STROBE EFFECT w/ decreasing speed
*
(avoid)
* 244 - 249 DMX RESET - puts unit in Test / Reset
250 - 255 SHUTTER OPEN
CH. 5 PAN 0 - 255 360 degrees
CH. 6 TILT 0 - 255 270 degrees
CH. 7 PRISM 0 - 15 WHITE
16 - 239 ROTATING PRISM SPEED
239 - 255 STOP, PRISM STATIC
CH. 8 FOCUS 0 - 255 MOTORIZED FOCUSING
CH. 9 SPEED 0 - 255 MOTOR SPEED PAN and TILT
CH. 10 PAN 0 - 255 PAN (fine adjust)
CH. 11 TILT 0 - 255 TILT (fine adjust)
