Thank you for purchasing this Team Associated Qualifier Series product. This manual contains
instructions and tips for maintaining your new APEX RTR. Please take a moment to read through it
and familiarize yourself with these steps as they will help you to understand each component’s
function and show you some tips for getting the most out of your APEX RTR. We are continually
changing and improving our designs; therefore, actual parts may appear slightly different than the
illustrations.
For more information, scan the QR code to the right for videos and
tutorials on the APEX RTR!
http://www.teamassociated.com/cars_and_trucks/Apex/RTR
• Fully assembled, shaft drive 4wd Touring car with gear differentials
• Water RESISTANT XP SC500-BL brushless electronic speed control with Deans® Ultra Plug®
(2S-3S LiPo compatible)
• Reedy WolfPack 7-cell NiMH Battery w/Deans® Ultra Plug® Connector
• Powerful Reedy 3300kV 540 brushless motor
• XP 2.4Ghz Radio system with XP metal gear steering servo
• Composite modular chassis accepts NiMH or LiPo type batteries
• 10 spoke Touring car wheels with high grip racing tires
• Factory-finished touring car race body
• Fluid filled adjustable shock absorbers
• All steel CVA drive axles front and rear
• All metric hardware and ball bearings throughout
• Sealed metal gear differentials
Your APEX RTR requires the following items to complete your kit:
• Transmitter batteries (x6 AA’s) (#302, 303 AA batteries recommended)
• NiMH Battery charger (peak detection charger recommended) (AE #604)
-OR- Wall charger (#29154) • Needle nose pliers • Hobby knife
• Reamer/hole punch • Ride Height Gauge (#1450 recommended)
• Silicone Shock Fluid / Differential Fluid (Refer to catalog for complete listings)
• Body Scissors (AE Part # 1737)
• FT Threadlock (#1596)
• FT Hex Wrenches (AE Part # 1541, 1655) • Multi Tool (AE Part #7494)
• FT Nut Drivers (AE Part #1561, 1663-1668) • Calipers or a Precision Ruler
• FT Turnbuckle Wrench (#1112) • Soldering Iron
• Green Slime shock lube (AE Part # 1105) • Wire cutters
:: Additional Items Needed
