13
Machine does not cycle
Symptom Possible Cause
Action
Troubleshooting
Die does not go into machine
1) Machine is off
2) Machine is not plugged in
3) Foot-pedal is not plugged into
machine
4) Die lock handle is not locked
5) Reversing tool is in machine
1) Pin retainer interference
2) Punch is stopped in mid cycle
3) Die lock handle is in lock position
1) Check power switch
2) Check both ends of power cord
3) Make sure foot-pedal cable is
attached to machine.
4) Lock the die lock handle
5) Remove reversing tool and
store properly
1) Make sure pin retainer enters slot
in pusher-bar.
2) Restart machine by turning power
off and back on
3) Move handle to unlock position
Only qualified personnel should attempt to
work on this equipment. There are no user
serviceable parts inside of the machine.
Your machine has been designed for years of trouble free operation. The
following is a troubleshooting guide to help you through some of the
problems that may be encountered.
The OD4012 has earned the UL Listing Mark. E179574.
The OD4012 and OD4000 have been tested with a
duty cycle of 25 cycles per minute with a 1 minute
rest period after 2 minutes of run time. Operating outside of these limits
could result in machine damage.
! DANGER
Hazardous voltage
inside.
Disconnect power
before servicing.
! NOTICE
