MIPRO ACT-70TC Rechargeable Wideband Bodypack Transmitter - Manual (Page 7)

8 9
Setting Input Gain Level
! Selectable between 12dB to -18dB
with 6dB parameter up or down selection.
! Press MODE button until mode
appears.
! Press SET button once to activate function.
! Press SET button to select the desired
sensitivity level.
! Press MODE button to confirm and save the
change.
! The higher the sensitivity level, the lower the
dynamic range of input signals. Meanwhile noise
will increase, and the feedback problem will be
getting more serious.
NOTE:
! The audio gain level is factory preset at 0dB
level.
! Guitar setting is recommended at -12dB
level.
AF GAIN
AF GAIN
0 dB
AF GAIN
6 dB
AF GAIN
12 dB
AF GAIN
0 dB -6 dB
AF GAIN AF GAIN
6 dB
AF GAIN
-12 dB
AF GAIN
-18 dB
AF GAIN
-12 dB
AF GAIN
-6 dB
AF GAIN
SET
SET
SET
SET
SET
SET
SET
SET
SET
SET
Setting RF Output Power
! 2 RF Output Power Levels: RF-LOW and RF-HI.
! Press MODE button until RF POWER mode
appears.
! Press SET button once to activate function.
! Press SET button to select the desired RF output
power.
! Press MODE button to confirm and save the
change.
RF-HI
RF POWER
RF-LOW
RF POWER
SET
Rechargeable Wideband Bodypack Transmitter Rechargeable Wideband Bodypack Transmitter
