MIPRO ACT-70TC Rechargeable Wideband Bodypack Transmitter - Manual (Page 11)

16 17
AUDIO
SHIELD
4
3
2
1
PIN
SHIELD
AUDIO
BIAS
3
4
PIN
1
2
AUDIO
SHIELD
1
4
3
2
PIN
SHIELD
AUDIO
3
2 1
PIN
4
3
2
1
SHIELD
AUDIO
1
3
4
2
PIN
AF Input Connections
(1) 2-Wire Electret condenser
microphone Capsule
(2) 3-Wire Electret condenser microphone Capsule
(3) Dynamic Microphone
(5) Line-in (Impedance 8KΩ ATT. 10dB)
(4) Electric Guitar
1 3
4
2
1 3
4
2
1 3
4
2
1 3
4
2
1 3
4
2
Battery Removal and Installation
! Pushing down both snap locks on the sides to
open battery compartment cover. Take out the
two batteries. (Figure 3)
!
Insert one charged 18500 rechargeable battery
into the battery compartment according to the
correct polarity (- and +) as shown in (Figure 4)
. Then close the battery compartment cover
tightly.
Caution
Remove the batteries if unused for a long period of
time to prevent battery leakage, corrosion and
causes possible damage to electronics.
(Figure 4) (Figure 3)
Rechargeable Wideband Bodypack Transmitter Rechargeable Wideband Bodypack Transmitter
