AF MUTE
718.275
MHz
FREQUENCY
 LCD Screen for function display
 AF (audio) MUTE
 Transmitter Battery Meter
A2
A3
A1
How to Setup Transmitter Parameters LCD Display Screen
! Remove protection cover to expose MODE
button and SET button.
! MODE Button:
Press “MODE” button to access one of the six
functions below.
! SET Button:
Press “SET” button and LCD wills start flashing.
During flashing, press SET button to change
parameters.
6 7
MODE
SET
718.275 MHz
FREQUENCY
Wideband Handheld Transmitter Wideband Handheld Transmitter
A1
A2 A3
F E
A
D
B C
B
A
C
D
E
F
718.275
MHz
FREQUENCY
0 dB
AF GAIN
7UA
BAND
MANUAL
MUTE MODE
RF-LOW
RF POWER
01 01
GRP CH
Group and Channel
Frequency
Sensitivity Level
RF Output Power
Frequency Band
MUTE Mode
