MIPRO ACT-80H Wideband Digital Handheld Transmitter - Manual (Page 7)

N O
ENCRYPTION
Y E S
AF LIMIT
MANUAL
MUTE MODE
486.500
MHz
FREQUENCY
0 dB
AF GAIN
LOW CUT
AF LOW-CUT
RF-LOW
RF POWER
Group and Channel
Frequency
Sensitivity Level
AF Low Cut
Encryption
RF Output Power
MUTE Mode
AF Limit
B
A
C
D
E
F
G
H
A
F
G
B
E
H
C
D
How to Setup Transmitter Parameters
! Remove protection cover to expose MODE
button and SET button.
! MODE Button:
Press “MODE” button to access one of the six
functions below.
! SET Button:
Press “SET” button and LCD wills start flashing.
During flashing, press SET button to change
parameters.
9 10
Wideband Digital Handheld Transmitter Wideband Digital Handheld Transmitter
MODE
SET
486.500 MHz
FREQUENCY
0 1 0 2
GRP CH
